full gigabit ports, suitable for broadband access over 200m
built-in pa signal amplifier, longer signal transmission distance
1ghz high-end chip 128m memory, stable capacity of 80 units
2.4g 5g dual-band integration, whole-house wi-fi, seamless roaming
wechat remote management, more convenient to set parameters
| product model | power 8s black |
| wireless protocol | ieee802.11 b/g/n/ac |
| port |
one 10/100/1000m adaptive wan port |
| forwarding rate | 10/100/1000mbps |
| wireless specifications | 2.4g band: 300mbps; 5g band: 867mbps |
| antenna | 6根7dbi高增益全向天线 |
| ram | 128mb |
| rom | 8mb |
| button | reset |
| led indicator |
1 green and 1 red led |
| button | default |
| dimensions | 182mm×108mm×25mm（antenna leveling） |
| power supply | 12v/1a |
| operating environment | operating temperature: 0°c ~ 40°c storage temperature: -20°c ~ 70°c operating humidity: 10% ~ 90%, non-condensing storage humidity: 5% ~ 90%, non-condensing |
| common functions | quick configuration one key speed test troubleshooting internet settings wi-fi settings signal conditioning wireless universal relay friends only network child mode indicator schedule off wi-fi schedule off port mapping peanut shell dynamic domain name indicator schedule off wi-fi schedule off internet blacklist internet host list one-click switch peanut shell domain name access |
| security | malicious url firewall internet hijacking firewall wi-fi squatter firewall home network firewall ddos firewall |
| basic settings |
system upgrade |
| others | wechat management plugin center emergency recovery |
