9ge ports, support gigabit bandwidth access, easy to run at full speed
up to 4wan port configuration, load balancing brings better broadband overlay effect
smart qos , always smooth
6*7dbi high-gain antennas, full coverage of corners
2.4g/5g signal concurrent, dual-band network transmission rate up to 1167m
wechat remote management, safer and more convenient
| product model | nb1209gc |
| wireless protocol | ieee802.3,ieee802.3u,ieee802.3z ,ieee802.3x,ieee802.1x,ieee802.11 b/g/n/ac |
| port |
1*10/100/1000m rj45 wan |
| forwarding rate | 10/100/1000mbps |
| wireless band | 2.4ghz：300mbps 5ghz：866mbps |
| flash | 16mb |
| memory | 128mb |
| size |
200mm×124.4mm×28mm |
| operating environment | operating temperature: 0°c ~ 40°c
storage temperature: -20°c ~ 70°c operating humidity: 10% ~ 90%, non-condensing storage humidity: 5% ~ 90%, non-condensing |
| led indicator | green pwr\sys\2.4g wifi\5g wifi |
| power | 12v/1a |
| common functions | multi-wan port access (support dynamic ip/pppoe/static ip dial-up mode, wan port automatically detects the access type)
one key speed test store scene settings wechat to wi-fione-click switch child mode, worry-free parent control one-click sos to restore user configuration smart qos dhcp service wisp universal relayport mapping peanut shell domain name access device monitoring pptp/l2tp client |
| security | malicious url blocking
lan attack defense anti-wi-fi squatter intrusion blacklist management |
| basic settings |
system upgrade restart router reset dial log |
| other | wechat management emergency recovery |
