equipped with 6dbi high-gain antenna, the signal coverage is expanded by more than 10%
support 32 devices online at the same time, stable signal, fast network speed
more than a good router
| protocol standard |
ieee 802.11n |
| wireless specifications | 2.2.4ghz frequency band：300mbps 2.4ghzchannel selection：1-13 |
| port |
4个10/100m adaptive lan port, support automatic rollover（auto mdi/mdix） |
| button | default button |
| wireless | four 5dbi external 2.4g non-removable antennas |
| led display | pwr：power status indicator sys：system status indicator light wifi：wifi status light wan:wan口link&act indicator lan：lan口link&act indicator |
| led indicator | 9 sapphire blue led indicator lights |
| dimensions | 195×133.58×25.34mm（l×w×h） |
| capacity storage | flash：4mb memory：32mb |
| packing list | 300mbps netcore wireless routing n11台 1 manual 1 power supply |
| working environment |
operating temperature: 0°c ~ 40°c |
| common functions | internet settings wi-fi settings signal conditioning wireless universal relay friends only network child mode indicator schedule off wi-fi schedule off port mapping peanut shell dynamic domain name one-click switch |
| security | malicious url firewall wi-fi squatter firewall internet hijacking firewall home network firewall ddos firewall |
| basic settings |
system upgrade |
| others | wechat management |
